Cabinet:

•Powdercoated 18 gauge cold rolled steel; multi-piece shell and frame design; riveted and press joined (Tog-L-Loc®)

Door Construction:

•Front/Back: 12 Mil. Seamless polymer-covered front; melamine back (Frost in color).

•Core: 45 lb. LEED IEQ compliant MDF board, 3/4 inch thick. All composite wood material to meet CARB P2 emission std of CARB reg. 91320.2.

•Hinges: Manufacturer’s standard Blum®, concealed, selfclosing, 110 deg. opening, nickel-plated metal, clip-on mount, three adjustment points.

•Pulls: 128 mm pull offering for Serenity, Transcend, and Pinnacle Style Panels; Integrated front pull design (Cove style); Recessed clear snap-on handle w/interchangeable color strips (Renew style).

Adjustable Shelving:

•Powdercoated 18 gauge cold rolled steel, painted to match cabinet color; manufacturer’s standard die cast zinc support clips.

Locks:

•Doors: Manufacturer’s standard Timberline, individually mounted, cam style lock removable lock plug; locks keyed alike with two keys per lock.

Drawers:

•Deep Drawer Construction: One piece molded polystyrene drawer bodies w/rounded corners; (Frost color).

•File Drawer Construction: 18 gauge cold rolled steel frame; including suspended file system/bars.

•Front/Back: 12 Mil. Seamless polymer-covered front; melamine back (Frost in color).

•Core: 45 lb. LEED IEQ compliant MDF board, 3/4 inch thick. All composite wood material to meet CARB P2 emission std of CARB reg. 91320.2.

•Slide: Manufacturer’s standard Accuride Aero (100 lb. capacity) ball bearing slides; Accuride Model 3832 (100 lb. capacity) for pullout writing surfaces and waste cans; and heavy duty Accuride Model 3640 (200 lb. capacity) slide for file drawers and heavy duty pull out shelves.

•Pulls: 128 mm pull offering for Serenity, Transcend, and Pinnacle Style Panels; Integrated front pull design (Cove style); Recessed clear snap-on handle w/interchangeable color strips (Renew style).

Locks:

•Drawers: Manufacturer’s standard Timberline lock body with removable lock plug with 14 gauge cold rolled steel pivoting lock bar for central lock system; locks keyed alike with two keys per lock.

Wall Mounted Sink, Corner Storage, Corner Sink, Desk, Exam, Combo Desk, Treatment Storage, 30 / 34 / 36 / 42 inch Storage, Base Sink, Sink W/Tapmaster, Combo 30 / 34 / 36 / 42 inch Storage

•Powdercoated 18 gauge cold rolled steel; multi-piece shell and frame design; riveted and press joined (Tog-L-Loc®)

•Front/Back: 12 Mil. Seamless polymer-covered front; melamine back (Frost in color).

•Core: 45 lb. LEED IEQ compliant MDF board, 3/4 inch thick. All composite wood material to meet CARB P2 emission std of CARB reg. 91320.2.

•Hinges: Manufacturer’s standard Blum®, concealed, selfclosing, 110 deg. opening, nickel-plated metal, clip-on mount, three adjustment points.

•Pulls: 128 mm pull offering for Serenity.

•Powdercoated 18 gauge cold rolled steel, painted to match cabinet color; manufacturer’s standard die cast zinc support clips.

•Doors: Manufacturer’s standard Timberline, individually mounted, cam style lock removable lock plug; locks keyed alike with two keys per lock.

•Powdercoated 18 gauge cold rolled steel; multi-piece shell and frame design; riveted and press joined (Tog-L-Loc®).

•Front/Back: 12 Mil. Seamless polymer-covered front; melamine back (Frost in color).

•Core: 45 lb. LEED IEQ compliant MDF board, 3/4 inch thick. All composite wood material to meet CARB P2 emission std of CARB reg. 91320.2.

•Hinges: Manufacturer’s standard Blum®, concealed, selfclosing, 110 deg. opening, nickel-plated metal, clip-on mount, three adjustment points.

•Pulls: 128 mm pull offering for Serenity, Transcend, and Pinnacle Style Panels; Integrated front pull design (Cove style); Recessed clear snap-on handle w/interchangeable color strips (Renew style).

•Deep Drawer Construction: One piece molded polystyrene drawer bodies w/rounded corners; (Frost color).

•File Drawer Construction: 18 gauge cold rolled steel frame; including suspended file system/bars.

•Front/Back: 12 Mil. Seamless polymer-covered front; melamine back (Frost in color).

•Core: 45 lb. LEED IEQ compliant MDF board, 3/4 inch thick. All composite wood material to meet CARB P2 emission std of CARB reg. 91320.2.

•Slide: Manufacturer’s standard Accuride Aero (100 lb. capacity) ball bearing slides; Accuride Model 3832 (100 lb. capacity) for pullout writing surfaces and waste cans; and heavy duty Accuride Model 3640 (200 lb. capacity) slide for file drawers and heavy duty pull out shelves.

•Pulls: 128 mm pull offering for Serenity.

•Powdercoated 18 ga. cold rolled steel, painted to match cabinet color; manufacturer’s standard die cast zinc support clips.

•Doors: Manufacturer’s standard Timberline, individually mounted, cam style lock removable lock plug; locks keyed alike with two keys per lock.

• Drawers: Manufacturer’s standard Timberline lock body with removable lock plug with 14 gauge cold rolled steel pivoting lock bar for central lock system; locks keyed alike with two keys per lock.
