Specifications

Equipment not suitable for use in the presence of a flammable anesthetic mixture with air, oxygen, or nitrous oxide.

Specifications
Patient Weight (max)	450 lbs (204 kg)
Weight of Chair	290 lbs (131 kg)
Power Cord Length	8 ft (244 cm)
Foot Control Voltage	10 VAC, SELV - Safety Extra Low Voltage
Chair Receptacle Maximum Load	115 VAC, 3 amps, 50 / 60 Hz
Duty Cycle (Motor Run Time)	Intermittent Operation - 30 seconds ON, 5 minutes OFF
Protection against ingress of fluids:	Ordinary Equipment Foot control only: IPX1
Classifications	Class 1, Type B, Applied Part
Electrical Requirements	Refer to: Model Identification / Compliance Chart
Regulatory Compliance	Refer to: Model Identification / Compliance Chart
