647 Chair Specifications
Equipment not suitable for use in the presence of a flammable anesthetic mixture with air, oxygen, or nitrous oxide.
|
Specifications |
|
|---|---|
| Patient Weight, Maximum |
450 lbs (204 kg) |
|
Weight of Chair
|
Standard Base 421 lbs (191 kg) |
|
Rotational Base 506 lbs (230 kg) |
|
|
Power Cord Length |
8 ft (244 cm) |
|
Fuses, located at power cord inlet |
6.3A, 250V, Type T, 0, 5 x 20mm |
|
Foot Control Voltage |
10 VAC, SELV, Safety Extra Low Voltage |
|
Chair Receptacle Maximum Load |
115 VAC, 3 amps, 50 / 60 Hz |
|
Duty Cycle, Motor Run Time |
Intermittent Operation, 30 seconds ON - 5 minutes OFF |
|
Protection against ingress of fluids |
Ordinary Equipment, Foot Control only: IPX1 |
|
Classifications |
Class I, Type B, Applied Part |
|
Electrical Requirements |
Refer to: Model Identification Chart |
|
Regulatory Compliance |
Refer to: Model Identification Chart |
