640 Doran Scale Exam Table Parameter Set-Up Mode Test and Repair
1.Enter Setup mode.
a.Press and hold Reweigh and Zero together.
b.Release both buttons when the display reads CAL n.
2.Navigate through each parameter to adjust desired user settings.
a.Press Length to scroll forward to each parameter.
b.Press + or - buttons to change the current parameter setting.
c.Press Reweigh to save any changes and exit setup mode.
| Reset All Parameters to Default Settings | |
|---|---|
|
rSt |
Default parameters |
|
n |
No. Parameters are not defaulted. (default) |
|
y |
Yes. Set all parameters to factory default values when Length is pressed. Calibration is preserved. |
| Automatic Shutoff Timer | |
|---|---|
|
Ao |
Automatic shutoff timer. The timer controls the period of time the scale stays on after non-use. |
|
0.2 |
12 Seconds |
|
0.5 |
30 Seconds (default) |
|
1 |
1 Minute |
|
2 |
2 Minutes |
|
5 |
5 Minutes |
|
10 |
10 Minutes |
|
15 |
15 Minutes |
|
on |
Automatic shutoff timer disabled. |
| Average Aperture | |
|---|---|
|
AA |
Determines the amount of motion allowed to hold a stable weight. A slower setting will result in more accurate weights, but will require a longer time to achieve a stable weight. A faster setting will achieve a stable weight faster, but may be less accurate. |
|
4 |
Fastest Setting |
|
8 |
Default Setting |
|
16 |
Slowest Setting |
| Data Output | |
|---|---|
|
d.o |
Parameter reserved for future use. Do not change. |
|
t.d. |
Default |
| EMR Format | |
|---|---|
|
For. |
Parameter reserved for future use. Do not change. |
|
IU |
Default |
| LB Units Enable / Disable | |
|---|---|
| lb | |
|
on |
lb weighing units active (default) |
|
of |
lb weighing units disabled |
| KG Units Enable / Disable | |
|---|---|
| kg | |
|
on |
kg weighing units active (default) |
|
of |
kg weighing units disabled |
| LB:OZ Units Enable / Disable | |
|---|---|
| lb:oz | |
|
on |
lb:oz weighing units active (default) |
|
of |
lb:oz weighing units disabled |
| Inches Units Enable / Disable | |
|---|---|
| ft:in | |
|
on |
in length units active (default) |
|
of |
in length units disabled |
| Centimeters Units Enable / Disable | |
|---|---|
| cm | |
|
on |
cm length units active (default) |
|
of |
cm length units disabled |
| Stable or Average Hold Weight Beep | |
|---|---|
|
bH |
bH Enables/Disables beep when a stable or average hold weight is achieved |
|
n |
Beep disabled (default) |
|
y |
Beep enabled |
| Voltage Level | |
|---|---|
|
dC |
8.8 Vdc - 9.6 Vdc |
| Raw Counts | |
|---|---|
| xxxx | Raw counts from A/D converter |
| View these numbers if calibration is unsuccessful. Refer to chart in Calibration section for interpretation of these numbers. Press Length or Reweigh to exit setup mode. | |
